Uagnpps | H45.092D
Hopper wagon
- Optimized for the transportation of sugar.
- Unloading hatches closed by slide valves operated manually and individually by handwheels on either side of the wagon.
- 25 t axles for enhanced safety.
- Complies with the strict hygienic requirements for the transportation of foodstuffs/sugar. Movable components made of stainless steel. Mechanical parts of the brake and the discharge mechanism are protected against sugar dust.
Industry
FoodLoads
GrainSugarTechnical data
Specifications H45.092D
| Axle load | 22.5 t |
|---|---|
| Brake | KE-GP-A 2x8" |
| Brake block category | K brake block |
| Clearance: outer wheelsets | 13,800 mm |
| Drawgear & static tractive force | Split, 850 kN |
| Lining type | Food-grade lining - Novatic ZD 95, solvent-free |
| Material, upper section | Steel (S355J2+N) |
| Min. curve radius | 75 m |
| Nominal volume | approx. 92 m³ |
| Tare weight | approx. 22.2 t |
| Wall inclination | 50° |
